Based on SDR jamming technology, Portable Counter-FPV Shield supports different frequency-band configurations and can effectively block UAV signals such as data/image transmission, remote control, navigation, etc., especially for various FPV drones with excellent countermeasure. It adopts an IP54 level ultra-durable shell, which is heat-resistant and corrosion-resistant. It can be quickly deployed in various scenarios such as counter-terrorism, important activities security protection, and base protection. Its appearance is concealed and not easy to cause panic.
Product Highlights
Effective Jamming with FPVs: By using digital modulation jamming sources, it can efficiently block FPV drones remote control and video transmission signals.
Portable and Concealed: Small in size and lightweight, flexible and portable; Shield-shaped design ensures high concealment, making it less likely to cause panic during use.
Flexible Jamming Options: Two models to choose (counter FPV only / counter UAV and FPV), accurately matching mission requirements.
Continuous Effectiveness: Based SDR architecture, it supports algorithm iteration to cope with future changes in drone technology.
Technical Specifications
|
Model |
AT-619A |
AT-619B |
|
Jamming Mechanism |
SDR Technology |
SDR Technology |
|
Jamming Frequency Bands |
800MHz~900MHz / 2.4GHz / 5.3GHz~5.9GHz |
800MHz~900MHz / 1.2GHz / 1.4GHz / 1.5GHz / 2.4GHz / 5.2GHz / 5.8GHz |
|
Defense Direction |
Directional jamming |
Directional jamming |
|
Jamming Distance |
FPV Drones:≥ 1km (Jamming/Communication Ratio =1:1) |
FPV Drones:≥ 1km (Jamming /communication ratio=1:1) Conventional UAVs ≥ 1km (jamming/Communication Ratio =2:1) |
|
Total Transmission Power |
<90W |
<130W |
|
Size |
440*250*150mm |
440*250*150mm |
|
Weight |
<4.5kg (Host with battery) |
<5.5kg (Host with battery) |
|
Power Supply/Charging |
Lithium battery pack; Supports battery pack replacement, and whole machine charging |
Lithium battery pack; Supports battery pack replacement, and whole machine charging |
|
Power Consumption |
<250W (Full-power transmission) <15W (Standby mode) |
<350W (Full-power transmission) <35W (Standby mode) |
|
Protection Level |
IP54 |
IP54 |
|
Working Temperature |
-30℃~+45℃ |
-30℃~+45℃ |
|
Working Humidity |
≤93%, no condensation water |
≤93%, no condensation water |
|
Storage Temperature |
-40℃~+70℃ |
-40℃~+70℃ |
